CIEL

CIEL is a collection of useful libraries.

It's Common Lisp, batteries included.

Questions, doubts? See the FAQ.

Install

With Quicklisp

You need a Lisp implementation and Quicklisp installed.

CIEL is not yet on Quicklisp (but it is on Ultralisp), so clone this repository and load the .asd (with load or C-c C-k in Slime).

git clone https://github.com/ciel-lang/CIEL ~/quicklisp/local-projects/CIEL

Then, quickload it:

(ql:quickload "ciel")

and enter the ciel-user package, instead of the default common-lisp-user (or cl-user):

(in-package :ciel-user)

With a core image

You need a Lisp implementation, but you don't need Quicklisp.

Build a core image for your lisp with all CIEL's dependencies:

sbcl --load build-image.lisp

and use it:

sbcl --core ciel --eval '(in-package :ciel-user)'

TODO: we will distribute ready-to-use core images.

With a binary

You don't need anything, just download the CIEL executable and run its REPL.

TODO: build it on CI for different platforms.

To build it, clone this repository and run make build.

Start it with ./ciel-repl.

You are dropped into a custom Lisp REPL.

CIEL's custom REPL

This REPL is more user friendly than the default SBCL one:

• it has readline capabilities, meaning that the arrow keys work by default (wouhou!) and there is a persistent history, like in any shell.

• it has multiline input.

• it has TAB completion.

• it handles errors gracefully: you are not dropped into the debugger and its sub-REPL, you simply see the error message.

• it has optional syntax highlighting.

• it defines short helper commands:

:help => Prints this general help message
:doc => Prints the available documentation for this symbol
:? => Gets help on a symbol <sym>: :? str
:w => Writes the current session to a file <filename>
:d => Dumps the disassembly of a symbol <sym>
:t => Prints the type of a expression <expr>
:lisp-critic => Toggles the lisp-critic
:q => Ends the session.

• it has a shell pass-through: try !ls.

Our REPL is adapted from sbcli. See also cl-repl, that has an interactive debugger.

Quick documentation lookup

The documentation fo a symbol is available with :doc and also by appending a "?" after a function name:

ciel-user> :doc dict
;; or:
ciel-user> (dict ?

Shell pass-through

Use ! to send a shell command:

!ls
Makefile
README.org
repl.lisp
repl-utils.lisp
src
...

!pwd
/home/vindarel/projets/ciel

Use square brackets [...] to write a shell script, and use $ inside it to escape to lisp:

(dotimes (i 7) (princ [echo ?i]))

The result is concatenated into a string and printed on stdout.

This feature is only available in CIEL's REPL, not on the CIEL-USER package.

We use the Clesh library.

See also SHCL for a more unholy union of posix-shell and Common Lisp.

Syntax highlighting

Syntax highlighting is off by default. To enable it, install pygments and add this in your ~/.cielrc:

(in-package :sbcli)
(setf *syntax-highlighting* t)

;; and, optionally:
;; (setf *pygmentize* "/path/to/pygmentize")
;; (setf *pygmentize-options* (list "-s" "-l" "lisp"))

You can also switch it on and off from the REPL:

(setf sbcli:*syntax-highlighting* t)

Friendly lisp-critic

The :lisp-critic helper command toggles on and off the lisp-critic. The Lisp Critic scans your code for instances of bad Lisp programming practice. For example, when it sees the following function:

(critique
   (defun count-a (lst)
     (setq n 0)
     (dolist (x lst)
       (if (equal x 'a)
         (setq n (+ n 1))))
     n))

the lisp-critic gives you these advices:

----------------------------------------------------------------------

SETS-GLOBALS: GLOBALS!! Don't use global variables, i.e., N
----------------------------------------------------------------------

DOLIST-SETF: Don't use SETQ inside DOLIST to accumulate values for N.
Use DO. Make N a DO variable and don't use SETQ etc at all.
----------------------------------------------------------------------

USE-EQL: Unless something special is going on, use EQL, not EQUAL.
----------------------------------------------------------------------

X-PLUS-1: Don't use (+ N 1), use (1+ N) for its value or (INCF N) to
change N, whichever is appropriate here.
----------------------------------------------------------------------
; in: DEFUN COUNT-A
;     (SETQ CIEL-USER::N 0)
;
; caught WARNING:
;   undefined variable: N
;
; compilation unit finished
;   Undefined variable:
;     N
;   caught 1 WARNING condition
=> COUNT-A

Libraries

To see the full list of dependencies, see the ciel.asd project definition or this dependencies list.

Data structures

Generic and nested access to datastructures (access)

From Access, we import access and accesses (plural).

It's always

(access my-structure :elt)

for an alist, a hash-table, a struct, an object… Use accesses for nested access (specially useful with JSON).

Hash-table utilities (Serapeum)

We import functions from Serapeum. https://github.com/ruricolist/serapeum/blob/master/REFERENCE.md#hash-tables

To see their full list with their documentation, see serapeum.

:dict
:do-hash-table ;; see also trivial-do
:dict*
:dictq  ;; quoted
:href  ;; for nested lookup.
:href-default
:pophash
:swaphash
:hash-fold
:maphash-return
:merge-tables
:flip-hash-table
:set-hash-table
:hash-table-set
:hash-table-predicate
:hash-table-function
:make-hash-table-function
:delete-from-hash-table
:pairhash

Here's how we can create a hash-table with keys and values:

;; create a hash-table:
(dict :a 1 :b 2 :c 3)
;; =>
(dict
 :A 1
 :B 2
 :C 3
)

In default Common Lisp, you would do:

  (let ((ht (make-hash-table :test 'equal)))
    (setf (gethash :a ht) 1)
    (setf (gethash :b ht) 2)
    (setf (gethash :c ht) 3)
    ht)
;; #<HASH-TABLE :TEST EQUAL :COUNT 3 {1006CE5613}>

As seen above, hash-tables are pretty-printed by default.

You can toggle the representation with toggle-pretty-print-hash-table, or by setting

(setf *pretty-print-hash-tables* nil)

in your configuration file.

Sequences utilities (Alexandria, Serapeum)

From Serapeum we import:

:assort
:batches
:runs
:partition
:partitions
:split-sequence

And from Alexandria:

:iota
:flatten
:shuffle
:random-elt
:length=
:last-elt
:emptyp

and some more.

String manipulation (str)

Available with the str prefix.

https://github.com/vindarel/cl-str/

Data formats

CSV

You have cl-csv, under its cl-csv package name and the csv local nickname.

;; read a file into a list of lists
(cl-csv:read-csv #P"file.csv")
=> (("1" "2" "3") ("4" "5" "6"))

;; read csv from a string (streams also supported)
(cl-csv:read-csv "1,2,3
4,5,6")
=> (("1" "2" "3") ("4" "5" "6"))

;; read a file that's tab delimited
(cl-csv:read-csv #P"file.tab" :separator #\Tab)

;; loop over a CSV for effect
(let ((sum 0))
  (cl-csv:do-csv (row #P"file.csv")
    (incf sum (parse-integer (nth 0 row))))
  sum)

See also:

• auto-text, automatic detection for text files (encoding, end of line, column width, csv delimiter etc). inquisitor for detection of asian and far eastern languages.
• CLAWK, an AWK implementation embedded into Common Lisp, to parse files line-by-line.

JSON

We use cl-json (GitHub). It has a json nickname.

To encode an object to a string, use encode-json-to-string:

(json:encode-json-to-string (list (dict :a 1)))
;; "[{\"A\":1}]"

To decode from a string: decode-json-from-string.

To encode or decode objects from a stream, use:

• encode-json object &optional stream
• decode-json &optional stream

as in:

(with-output-to-string (s)
   (json:encode-json (dict :foo (list 1 2 3)) s))
;; "{\"FOO\":[1,2,3]}"

(with-input-from-string (s "{\"foo\": [1, 2, 3], \"bar\": true, \"baz\": \"!\"}")
  (json:decode-json s))
;; ((:|foo| 1 2 3) (:|bar| . T) (:|baz| . "!"))

cl-json can encode and decode from objects. Given a simple class:

(defclass person ()
  ((name :initarg :name)
   (lisper :initform t)))

We can encode an instance of it:

(json:encode-json-to-string (make-instance 'person :name "you"))
;; "{\"NAME\":\"you\",\"LISPER\":true}"

By default, cl-json wants to convert our lisp symbols to camelCase, and the JSON ones to lisp-case. We disable that in the ciel-user package.

You can set this behaviour back with:

(setf json:*json-identifier-name-to-lisp* #'json:camel-case-to-lisp)
(setf json:*lisp-identifier-name-to-json* #'json:lisp-to-camel-case)

Date and time

The local-time package is available.

See also awesome-cl#date-and-time and the Cookbook.

Databases

Mito and SxQL are available.

https://lispcookbook.github.io/cl-cookbook/databases.html

Numerical and scientific

Plotting

We import the vgplot plotting library, an interface to gnuplot.

It has a very good demo: just call

(vgplot:demo)

Here's a simple example to create a new plot:

 (vgplot:plot #(1 2 3) #(0 -2 -17) "silly example")
 (vgplot:title "Simple curve")
 (vgplot:text 1.2 -14 "Plot vectors with legend and add a title")

This will open a gnuplot window, which you can interfere with by entering more vgplot commands.

format-plot allows direct commands to the running gnuplot process:

(vgplot:format-plot t "set size square 0.5,0.5~%")
(vgplot:replot)

You can open other plots in parallel with new-plot, and create subplots in the same window with subplot.

You can graph data from files:

(vgplot:plot (first (vgplot:load-data-file "data.csv")))

Close plots with close-plot or close-all-plots.

Explore the demo here.

GUI (ltk)

We ship ltk.

The Tk toolkit is nearly ubiquitous and simple to use. It doesn't have a great deal of widgets, but it helps anyways for utility GUIs. Moreover, it doesn't look aweful (as it did back), it has themes to look nearly native on the different platforms.

Here's how it looks like on Mac:

You have other GUI options a quickload away (Qt4, Gtk, IUP, Nuklear, not mentioning LispWorks CAPI…): https://lispcookbook.github.io/cl-cookbook/gui.html

Here's how to start with Ltk:

• either put yourself in the ltk-user package:

(in-package :ltk-user)

• either use ltk:

(use-package :ltk)

Use the with-ltk macro to define your GUI, use make-instance + a widget name to create it, and use the grid to position widgets.

(with-ltk ()
  (let ((button (make-instance 'button :text "hello")))
    (grid button 0 0)))

Read more: https://lispcookbook.github.io/cl-cookbook/gui.html#tk

Iteration

We ship iterate and for so you can try them, but we don't import their symbols.

See https://lispcookbook.github.io/cl-cookbook/iteration.html for examples, including about the good old loop.

We import macros from trivial-do, that provides dolist-like macro to iterate over more structures:

• dohash: dohash iterates over the elements of an hash table and binds key-var to the key,

value-var to the associated value and then evaluates body as a tagbody that can include declarations. Finally the result-form is returned after the iteration completes.

• doplist: doplist iterates over the elements of an plist and binds key-var to the key, value-var to

the associated value and then evaluates body as a tagbody that can include declarations. Finally the result-form is returned after the iteration completes.

• doalist: doalist iterates over the elements of an alist and binds key-var to the car of each element,

value-var to the cdr of each element and then evaluates body as a tagbody that can include declarations. Finally the result-form is returned after the iteration completes.

• doseq*: doseq* iterates over the elements of an sequence and binds position-var to the index of each

element, value-var to each element and then evaluates body as a tagbody that can include declarations. Finally the result-form is returned after the iteration completes.

• doseq: doseq iterates over the elements of an sequence and binds value-var to successive values

and then evaluates body as a tagbody that can include declarations. Finally the result-form is returned after the iteration completes.

• dolist*: dolist* iterates over the elements of an list and binds position-var to the index of each

element, value-var to each element and then evaluates body as a tagbody that can include declarations. Finally the result-form is returned after the iteration completes.

Pattern matching

Use Trivia, also available with the match local nickname.

Numerical and scientific

We import mean, variance, median and clamp from Alexandria.

We import functions to parse numbers (Common Lisp only has parse-integer by default).

parse-float

Similar to PARSE-INTEGER, but parses a floating point value and returns the value as the specified TYPE (by default *READ-DEFAULT-FLOAT-FORMAT*). The DECIMAL-CHARACTER (by default #.) specifies the separator between the integer and decimal parts, and the EXPONENT-CHARACTER (by default #e, case insensitive) specifies the character before the exponent. Note that the exponent is only parsed if RADIX is 10.

ARGLIST: (string &key (start 0) (end (length string)) (radix 10) (junk-allowed nil)
        (decimal-character .) (exponent-character e)
        (type *read-default-float-format*))

From parse-number, we import:

:parse-number
:parse-positive-real-number
:parse-real-number

PARSE-NUMBER
  FUNCTION: Given a string, and start, end, and radix parameters,
  produce a number according to the syntax definitions in the Common
  Lisp Hyperspec.
  ARGLIST: (string &key (start 0) (end nil) (radix 10)
          ((float-format *read-default-float-format*)
           *read-default-float-format*))

See also cl-decimals to parse and format decimal numbers.

We don't ship Numcl, a Numpy clone in Common Lisp, but we invite you to install it right now with Quicklisp:

(ql:quickload "numcl")

Regular expressions

Use ppcre.

See https://common-lisp-libraries.readthedocs.io/cl-ppcre and https://lispcookbook.github.io/cl-cookbook/regexp.html

Threads, monitoring, scheduling

We ship:

Bordeaux-Threads (bt prefix)

Lparallel

Moira (monitor and restart background threads)

trivial-monitored-thread

Trivial Monitored Thread offers a very simple (aka trivial) way of spawning threads and being informed when one any of them crash and die.

cl-cron (see the sources on our fork here)

For example, run a function every minute:

(defun say-hi ()
  (print "Hi!"))
(cl-cron:make-cron-job #'say-hi)
(cl-cron:start-cron)

Wait a minute to see some output.

Stop all jobs with stop-cron.

make-cron's keyword arguments are:

(minute :every) (step-min 1) (hour :every) (step-hour 1) (day-of-month :every)
(step-dom 1) (month :every) (step-month 1) (day-of-week :every)
(step-dow 1)
(boot-only nil) (hash-key nil))

HTTP and URI handling

See:

• Dexador. Use the dex nickname or the http local nickname.
• Quri
• Lquery

(dex:get "http://my.url")

Web

We ship:

• Hunchentoot
• Easy-routes

https://lispcookbook.github.io/cl-cookbook/web.html

Conditions

See https://lispcookbook.github.io/cl-cookbook/error_handling.html

From Serapeum, we import ignoring.

An improved version of ignore-errors. The behavior is the same: if an error occurs in the body, the form returns two values, nil and the condition itself.

ignoring forces you to specify the kind of error you want to ignore:

(ignoring parse-error
          ...)

Types, type checking, exhaustiveness type checking

From Serapeum, we import:

:etypecase-of
:ctypecase-of
:typecase-of
:case-of
:ccase-of

etypecase-of allows to do compile-time exhaustiveness type checking.

Example with enums

We may call a type defined using member an enumeration. Take an enumeration like this:

(deftype switch-state ()
  '(member :on :off :stuck :broken))

Now we can use ecase-of to take all the states of the switch into account.

(defun flick (switch)
  (ecase-of switch-state (state switch)
    (:on (switch-off switch))
    (:off (switch-on switch))))
=> Warning

(defun flick (switch)
  (ecase-of switch-state (state switch)
    (:on (switch-off switch))
    (:off (switch-on switch))
    ((:stuck :broken) (error "Sorry, can't flick ~a" switch))))
=> No warning

Example with union types

(defun negative-integer? (n)
  (etypecase-of t n
    ((not integer) nil)
    ((integer * -1) t)
    ((integer 1 *) nil)))
=> Warning

(defun negative-integer? (n)
  (etypecase-of t n
    ((not integer) nil)
    ((integer * -1) t)
    ((integer 1 *) nil)
    ((integer 0) nil)))
=> No warning

See Serapeum's reference.

More type definitions (trivial-types)

From trivial-types, we import

• association-list-p
• type-expand
• string-designator
• property-list
• tuple
• association-list
• character-designator
• property-list-p
• file-associated-stream-p
• type-specifier-p
• list-designator
• package-designator
• tuplep
• non-nil
• file-associated-stream
• stream-designator
• function-designator
• file-position-designator
• pathname-designator

Syntax extensions

Arrow macros

We provide the Clojure-like arrow macros and "diamond wands" from the arrow-macros library.

;; -> inserts the previous value as its first argument:
(-> "  hello macros   "
  str:upcase
  str:words) ; => ("HELLO" "MACROS")

;; ->> inserts it as its second argument:
(->> "  hello macros   "
  str:upcase
  str:words
  (mapcar #'length)) ; => (5 6)


;; use as-> to be flexible on the position of the argument:
(as-> 4 x
  (1+ x)
  (+ x x)) ; => 10

And there is more. All the available macros are:

:->
:->>
:some->
:some->>
:as->
:cond->
:cond->>
:-<>
:-<>>
:some-<>
:some-<>>

Pythonic triple quotes docstring

https://github.com/smithzvk/pythonic-string-reader

We can use triple quotes for docstrings, and double quotes within them.

(defun foo ()
  """foo "bar"."""
  t)

Lambda shortcuts

You have to enable cl-punch's syntax yourself.

https://github.com/windymelt/cl-punch/ - Scala-like anonymous lambda literal.

(cl-punch:enable-punch-syntax)

;; ^() is converted into (lambda ...) .
;; Each underscore is converted into a lambda argument.

(mapcar ^(* 2 _) '(1 2 3 4 5))
;; => '(2 4 6 8 10)

;; One underscore corresponds one argument.

(^(* _ _) 2 3)
;; => 6

;; <_ reuses last argument.

(mapcar ^(if (oddp _) (* 2 <_) <_) '(1 2 3 4 5))
;; => '(2 2 6 4 10)

;; _! corresponds one argument but it is brought to top of the argument list.
;; It can be useful when you want to change argument order.

(^(cons _ _!) :a :b)
;; => (:b . :a)

(^(list _! _! _!) 1 2 3)
;; => '(3 2 1)

Development

Testing (Fiveam)

The FiveAM test framework is available for use.

Below we create a package to contain our tests and we define the most simple one:

(defpackage ciel-5am
  (:use :cl :5am))

(in-package :ciel-5am)

(test test-one
  (is (= 1 1)))

Run the test with:

(run! 'test-one)

Running test TEST-ONE .
 Did 1 check.
    Pass: 1 (100%)
    Skip: 0 ( 0%)
    Fail: 0 ( 0%)

T
NIL
NIL

If the test fails you will see explanations:

> (run! 'test-one)

Running test TEST-ONE .f
 Did 2 checks.
    Pass: 1 (50%)
    Skip: 0 ( 0%)
    Fail: 1 (50%)

 Failure Details:
 --------------------------------
 TEST-ONE []:

1

 evaluated to

1

 which is not

=

 to

2


 --------------------------------

NIL
(#<IT.BESE.FIVEAM::TEST-FAILURE {1007307ED3}>)
NIL

Use run to not print explanations.

You can use (!) to re-run the last run test.

You can ask 5am to open the interactive debugger on an error:

(setf *debug-on-error* t)

Logging (log4cl)

https://github.com/sharplispers/log4cl/

(log:info …)

Discoverability of documentation (repl-utilities' readme, summary,…)

We use readme and summary from repl-utilities.

Learn more with:

(readme repl-utilities)

printv

printv

 (:printv
  (defvar *y*)
  (defparameter *x* 2)
  (setf *y* (sqrt *x*))
  (setf *y* (/ 1 *y*)))

;; This produces the following text to PRINTV's output stream, and still results in the same returned value: 0.70710677.

;;;   (DEFVAR *Y*) => *Y*
;;;   (DEFPARAMETER *X* 2) => *X*
;;;   (SETF *Y* (SQRT *X*)) => 1.4142135
;;;   (SETF *Y* (/ 1 *Y*)) => 0.70710677

Getting a function's arguments list (trivial-arguments)

https://github.com/Shinmera/trivial-arguments

(defun foo (a b c &optional d) nil)
(arglist #'foo)
;; (a b c &optional d)

generic-cl

https://github.com/alex-gutev/generic-cl/

todo:

generic-ciel

Example:

;; with a struct or class "point":
(defmethod equalp ((p1 point) (p2 point))
   (…))

FAQ

See it here: FAQ.

Final words

That was your life in CL:

and now:
